Meade Instruments 10" F/10 ACF OTA W/UHTC - 1010-60-01

Meade InstrumentsSKU: 1010-60-01

Sale price$3,499 CAD
In stock (2 units), ships same day weekdays if ordered by 2pm EST!



  • 10" f/10 Advanced Coma Free Optics - 2500mm focal length
  • Ultra-High Transmission Coatings (UHTC)
  • Primary mirror lock for increased image stablilty
  • Oversized low-expansion borosilicate primary mirror
  • Losmandy wide style mounting rail

Advanced Coma-Free LX200 Optical Tube comes with Meade's Ultra-High Transmission Coatings (UTHC), Oversized Low-Expansion Borosilicate Primary Mirror, Schott Borofloat Glass Corrector Plate, Diffraction Limited Optics, Losmandy-style dovetail, and Dust Cover.

The Advanced Coma-Free (ACF) optical system has brought the highest level of optical performance well within the reach of most amateurs. Using the Meade exclusive design, ACF optics achieve aplanatic performance - with a flatter field, reduced astigmatism and eliminated diffractions spikes. Coupled with Meade's Ultra-High Transmission Coatings (standard on all LX200-ACF systems), you have the ultimate in premium optics.

The optical path and components of the ACF telescope design

The optical path and components of the ACF telescope design

All LX200 models feature a primary mirror locking mechanism, which effectively prevents movement of the primary mirror during long exposure astrophotography or observing. Turn the lock knob located just above the telescopes main focus knob and the progressive-tension primary lock completely cancels any residual image shift due to mirror movement during visual, photographic, or imaging applications.

The 10" LX200 Optical Tube Assembly has a 2500mm focal length, an f/10 focal ratio, and weighs 26lbs.

Designed and manufactured in North America.

Limited Warranty against defects in materials or workmanship for two years from date of purchase. This warranty is provided by Meade for the benefit of the original retail purchaser only. For complete warranty details contact Meade at 800-626-3233.
Best for viewingFainter deep sky
Best for imagingSolar, lunar, planetary & Messier objects
Astro-imaging capabilityLunar, planetary & long exposure
User levelAdvanced
Optical designAdvanced Coma-Free (ACF)
Optical diameter254mm
Focal length2500mm
Focal ratiof/10.0
Resolving power0.46arc*sec
Lowest useful magnification36x
Highest useful magnification300x
Highest theoretical magnification500x
Limiting stellar magnitude14.7
Optical qualityDiffraction limited
Finder scope5x24
Mount typeOptical Tube without Mount
Tube materialAluminum
Weight, optical tube26.0 lbs.
Additional included accessoriesLosmandy style dovetail bar
Other featuresUltra High Transmission Coatings (UHTC)
WarrantyTwo year
