iOptron HAE18C Ultra Compact GoTo Dual AZ/EQ Hybrid Strain Wave Gear Drive Mount - HE182C

iOptronSKU: HE182C

Price:
Sale price$2,169 CAD
Stock:
Back-Ordered - Place an Order to Reserve Yours, Otherwise Enter Your Email Address Further Below to be Notified When it's Back in Stock.      Click Here to ask us about back-ordered product availability

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
Description

Introducing the iOptron AZ/EQ Dual SWG Mount HAE18C! This light weight, compact, dual strain wave gear (SWG) mount delivers an incredibly portable astronomy experience. Weighing in at just 6.2 lb. with a payload of 18.7 lb. without a counterweight or up to 26 lb. with a counterweight the HAE18C is destined to be a compelling choice for astronomers on the go (counterweight shaft and counterweight not included); which comes as no surprise given iOptron's multi-decade experience creating compact precision mounts with unheard of payload to weight ratios. Utilizing state of the art strain wave gear technology on both the RA and DEC axis, the HAE18C delivers the tracking accuracy users have come to expect from iOptron mounts. With sleek features like an all black anodized, CNC machined, metal body and stationary inputs for power and USB, the HAE18C is not only appealing to the eye, it's a rugged platform that will perform at the highest level for many years. Unique features include an electronic friction brake that locks the mount when power cuts out, upgradable firmware, built-in WI-Fi, and zero position locator. The HAE18C mount can be controlled by a computer, either via ASCOM/ iOptron Commander for Windows PCs, third party INDI drivers for MacOS, Raspberry Pi, or Linux devices — or through a smartphone/ tablet via the iOptron Commander Lite app or SkySafari.

  • Payload Capacity: 18.7 lb. w/o Counterweight; 26 lb. w/ Counterweight (Not Included)
  • Mount Gear Type: Strain Wave Gear (RA and DEC Axis)
  • Mount Weight: 6.2 lb.
  • Wi-Fi Built-In: Yes
  • Hand Controller: Compatible with iOptron GOTONova Controller 8411 (Sold Separately)
  • Software Control: ASCOM/ iOptron Commander (Windows), INDI (Linux, MacOS), iOptron Commander Lite (Android/ iOS)
  • Tripod Included: No
Model Number
HE182C
Mount Type
Dual Alt-Az/Equatorial
Type of Mount Electronics
Computerized - GoTo
Weight Capacity (lb.)
18.7 lb. w/o Counterweight; 26 lb. w/ Counterweight
Mount Includes Tripod or Pier?
No
Power Failure Protection Included?
Yes
Drivers Available
Both ASCOM and INDI
Includes Integrated WiFi?
Yes
Saddle Type
Dual - Vixen or Losmandy
Hand Controller Included
No
Polar Scope Included?
No
Mount Weight (lb.)
6.2 lb.
