Description
- Eyepiece clamp (12 mm backfocus)
- Both sides of the clamp are equipped with M68 male threads
- Integrate this 2" clamp into a series of M68 extension rings
- Mounts onto all Baader Steeltrack and 3.5" Hyperion focusers
- 12.4 mm backfocus when using M68 thread, 17.4 mm when using M60 thread
Specifications
| Manufacturer | Baader Planetarium |
|---|---|
| SKU (#) | 2458196 |
| EAN Code | 4047825010032 |
| Weight (kg) | 0.168 |
| Optical length (mm) | 12.4mm at M68, 17.4mm at M60 |
| Clamping System | Screw clamps |
| Screw Type | 3x M4 clamping screws |
| Inner Diameter / Clear Aperture (mm) | 50,8 (2") |
| Outer Diameter | 75 |
| Outer Connection (lens sided) | Thread, M60, M68 x 1 |
| Inner Connection (eyepiece/-camera-sided) | Clamp, 2" (50,8mm) |
| Outer Connection (eyepiece/-camera-sided) | Thread, M68 x 1 |
| Compatible Brands | UNC, Baader Planetarium, Celestron, Sky-Watcher, Vixen, Zeiss |
| Type of Adapter | Eyepiece Clamp, Reducing piece |
