Description
The image sensor uses dark light compensation technology to greatly improve the camera's image clarity in low light conditions;
In MJPG video format;you can record video quickly and the frame rate up to 30FPS at 2K resolution 1920x1080; You can also choose YUV uncompressed video format;
The camera allows you to capture a real-time video and transport to your laptop or PC;machined aluminum 1.25" adapter barrel for direct threaded connection to almost any telescope.
| Model | SV205 |
| Sensor | 1/3.2" CMOS Color |
| Sensor Model | SONY IMX179 |
| Pixel Size | 1.4µmx1.4µm |
| Resolution | 8M Pixels(3264*2448 YUV 15FPS/S)2592*1944 YUV 24FPS/S1920*1080 YUV 30FPS/S |
| USB Type | USB3.0 |
| Shutter | Electronic Rolling Shutter |
| Exposure Time | 15ms~500ms |
| Gain | 0-120 |
| Maximum Frame Rate | 15FPS(3264*2448)30FPS(1920*1080) |
| ADC | 10 bit |
| Interface Type | Standard UVC protocol |
| Support OS | Windows, Linux, Raspberry Pi, and Android |
| Support Telescope | Telescope with 1.25'' diagonal base hole |
| Power Consumption | 230mA@5V |
| Cable Length | 1.8m |
