Name: Buckeye Stargazer 3D-Printed Mounting Bars, Saddles, and Tripod Clips
Brand: Buckeye Stargazer
SKU: VBar
Price: 18.0 CAD
Availability: InStock

Buckeyestargazer brackets for Pegasus Powerboxes, MiniPCs, and focuser controllers use various attachments for mounting on several different dovetail bars, finder shoes or tripod legs.

On this page you can order additional attachments. For example, if you bought a PPBA-Bracket + VSaddle attachment, but you now have Losmandy style dovetail bars, you can order an additional LSaddle without buying the PPBA-Bracket again.

NOTE: All stocked parts are currently in BLACK only

Rail/Dovetail Attachments

VBar: V-type bar that slips into a V-type clamp
ArcaSwiss-Bar: Arca-Swiss bar that slips into an Arca-Swiss clamp
Synta-Bar-20mm: Synta/Vixen bar that slips into a Synta finder base, 20mm tall
Synta-Bar-50mm: Synta/Vixen bar that slips into a Synta finder base, 50mm tall

LSaddle: Losmandy saddle that allows mounting to Losmandy/"D" rails
VSaddle: V-type saddle that allows mounting to a V-bar/rail
ADM-MDS-Saddle: ADM MDS saddle that clamps to a MDS style bar
ArcaSwiss-Saddle: Arca-Swiss saddle that allows for mounting to an Arca-Swiss rail

Round Leg Tripod Attachments

Tripod-1.20: 1.20" legs (Skywatcher AZ-GT, A25, StarAdventure, SolarQuest)
Tripod-1.25: 1.25" legs (iOptron SmartStar, iPano, SkyGuider Pro, SkyTracker, SmartEQ/Cube)
Tripod-1.50: 1.50" legs (iOptron ZEQ25, CEM25, MiniTower, iEQ30, SkyGuide)
Tripod-1.75: 1.75" legs (iOptron LiteRoc; Sky-Watcher AZ-EQ5/EQM-35/HEQ5)
Tripod-2.00: 2.00" legs (Skywatcher AZ EQ6, EQ6-RPro; iOptron MiniTower-Pro, iEQ45/CEM60; Meade Standard Field Tripod; Celestron Heavy Duty Tripod, AVX Tripod, CGX Tripod)
Tripod-2.36: 2.36" legs (Skywatcher EQ8)
Tripod-2.75: 2.75" legs (Celestron CGX-L)
Tripod-3.00: 3.00" legs (Meade Giant Field Tripod; Losmandy HD Tripod)

Other Tripod/Pier Attachments

Tripod-TriPier: iOptron Tri-Pier (NOTE: this will NOT fit the Tri-Pier 360)
Tripod-LosLW-v1: Losmandy LW Tripod (Pre-2011)
Tripod-LosLW-v2: Losmandy LW Tripod (2011 and later)
Pier-APEagle: Astro-Physics Eagle Pier
